home > Product introduction >200L drum filling >Pallet drum filling machine |
|
| |
|
| |
 |
| |
 |
|
 |
| |
- Sequentially filled into the four drums stocked
on the pallet
- The high precision filling with the automatic
return to zero during each drum filling
- The structure with the filling valve moving
forward, backward, left, and right conveniently
- The structure responding to various drum
dimensions
- Possible to flexibly change the filling quantity
- The structure useful for space utilization in the
small workplace
- Possible to selectively order the explosion
proof or non-explosion proof depending on the
site conditions
-
Possible to select the type of burial on the
ground or under the ground
|
 |
| |
- Filling 60L, 100L, and 200L drums and filling
IBC and POLY TANK
- Directly filling the drums stocked on the pallet
- Resin, solvent, and varnish products
- Food and beverage products such as liquid
sugar, cooking oil, and resin
- Liquid chemicals
|
|
|
| |
 |
| |
 |
|
| |
- The automatic filling line of various cans
- The semi-automatic filling system of various
cans
- The automatic and semi-automatic drum filling
systems
- The metallic and plastic pail can filling system
- The automatic empty cans storage and feeding
system
- he automatic division packing and stocking
system
- The automatic cap feeding and fastening
system (capper)
- Automatic pallet feeder and the pallet banding
system
- The automatic toning system (painting system)
|
 |
| |
- Filling range : 250kg×4drums
- Filling accuracy : ±0.2kg/drums
- Filling speed : 30 drums or more/hr
(in linkage with the flow)
- Up/down range : 100~400mm(H)
- Explosion-proof type available
- Power : 220V/380VAC, 50/60HZ, 1KVA
- Air Pressure : 4~7kg/㎤, 50~70Nℓ/min
- OPTION
..＊Possible to select the structure under the
ground or on the ground
..＊Possible to apply the driving roller conveyor
|
|
|
| |
| |
|
|
|
