- Preventing the muscle and bone diseases by automating the process of stocking heavy pallets
- Workers don’t have to work on and monitor the palletization process.
- Possible to be simply installed and used in the end of the current automatic and semi- automatic filling system
- The easy operation method that can be utilized easily without the separate use education
- Possible to install it in the small area and easy to move and install it
- Possible to maximize the investment effect by realizing the low price
- No can damage during palletization since cans are absorbed and stocked in vacuum
- Palletizer of 18L square cans
- Palletizer of 20L pail cans (PE and steel)
- Palletizer of product boxes
- Simple automated stocking in the end of the filling machine
- The automatic filling line of various cans
- The semi-automatic filling system of various cans
- The automatic and semi-automatic drum filling systems
- The metallic and plastic pail can filling system
- The automatic empty cans storage and feeding system
- The automatic division packing and stocking system
- The automatic cap feeding and fastening system (capper)
- Pallet feeder and the pallet banding system
- The automatic toning system (painting system)
- Palletizing weight : 10~50kg/can
- Can specification : by customer
- Palletizing Speed : 240~360 cans/hr
- Palletizing pattern 4×5Row×3(2)Bundle(Possible to select others)
- Power : 220/380VAC, 50/60㎐ , 5KVA
- Air Pressure : 5~7㎏/㎠, 300Nℓ/min
- OPTION ..＊Labeller, Ink Jet Printer ..＊Explosion proof
