- All kinds of gas generated during filling are
   collected and discharged.
- The dust in the production site is blocked to
  prevent the contamination of filling.
- Workers are protected from harmful steam or
  gas to prevent industrial disasters.
- It is easy to replace various filling valves
  depending on the items produced.
- Automatic drip prevention function (Drip tray)
- It is easy to do the work with the automatic error
  warning and message functions.
- Checking the error of the inlet position and the
  existence of a can during filling
- Possible to install it in the small area and easy
  to move and install it
- Possible and convenient to additionally install
  the can feeder and the palletizer


  - Filling of flammable or clean materials
- The product with the harmful gas or steam
  occurring
- Food or chemical preventing contamination





- The automatic filling line of various cans
- The semi-automatic filling system of various
   cans
- The automatic and semi-automatic drum filling
   systems
- The metallic and plastic pail can filling system
- The automatic empty cans storage and feeding
   system
- The automatic division packing and stocking
  system
- The automatic cap feeding and fastening
   system (capper)
- Pallet feeder and the pallet banding system
- The automatic toning system (painting system)


  - Filling weight : 10~35Kg/can
- Filling accuracy : 1/500~1/1000
- Can specification : by customer
- Filling Speed : 440∼600cans/hr
- Power : 220/380VAC, 50/60㎐
- Air Pressure : 5∼7Kg/㎠
- OPTION
..*Can eject part, palletizer ..Labeller, Ink Jet ...
......Printer
..*Banding (Strapping) machine ..Explosion-
...... proof
