- Possible to realize the automation in the small workplace
- Maximizing the work efficiency with the minimal number of staffs
- Possible to easily manipulate it due to the simple operating instructions
- Easy to clean it after usage and with the small quantity of cleanser
- Little failure due to the simple structure
- Possible to make a selective order of one nozzle depending on the production quantity
- Possible to make a selective order of an explosion proof item or a non-explosion proof item depending on the site conditions
- Possible to expand it if a capping system is needed
- Filling the 4~10L small cans
- Filling each 18L can / 20L PAIL
- Filling various containers such as P.E BOTTLE
- The automatic filling line of various cans
- The semi-automatic filling system of various cans
- The automatic and semi-automatic drum filling systems
- The metallic and plastic pail can filling system
- The automatic empty cans storage and feeding system
- The automatic division packing and stocking system
- The automatic cap feeding and fastening system (capper)
- Pallet feeder and the pallet banding system
- The automatic toning system (painting system)
SPECIFICATION
- Weighing range: 5~30kg
- Filling accuracy : 1/500~1/1000
- Filling speed : 240~300 can/hr
(in linkage with the flow quantity)
- 2-Step valve control
- Can specification : By costomer
- Power : 220V/380VAC, 50/60HZ, 2KVA
- Air Pressure : 4~7kg/㎤, 50Nℓ/min
- OPTION ..＊Capping machine ..＊Auto labeler
